| RZ4E 4X2 LS MT | RZ4E 4X2 LS AT | RZ4E 4X2 LS‑A MT | RZ4E 4X2 LS‑A AT | 3.0L 4X2 LS‑A AT | 3.0L 4X4 LS‑A AT | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | RZ4E-TC | 4JJ1-TCX | |||||||||||
| Type | 4-Cylinder In-line Blue Power Diesel Engine with Turbo Intercooler | ||||||||||||
| Maximum Power | PS (kW) @ rpm | 150 (110)@3,600 | 177(130)@3,600 | ||||||||||
| Maximum Torque | N-m (kg-m) @ rpm | 350 (35.7)@1,800 - 2,600 | 380(38.7)@ 1,800-2,800 | ||||||||||
| Displacement | cc | 1,898 | 2,999 | ||||||||||
| Bore X Stroke | mm | 80 X 94.4 | 95.4 X 104.9 | ||||||||||
| Compress Ratio | 16.5:1 | 17.3:1 | |||||||||||
| Fuel Tank Capacity | Liters | 65L Plastic with Roll Over Valve | |||||||||||
| Fuel System | Common Rail Direct Injection | ||||||||||||
| Turbocharger | Water Cooled Variable Geometry System (VGS) | Variable Geometry System | |||||||||||
| Emission rating | EURO 4 | ||||||||||||
POWER & STYLE
Models & Prices
3.0 LS-A 4x2 AT
₱ 1,795,000
3.0 LS-A 4x4 AT
₱ 2,145,000
RZ4E LS-A 4x2 MT
₱ 1,670,000
RZ4E LS 4X2 AT
₱ 1,350,000
— Prices / Specifications may change without prior notice.
— Shipping and handling charges are not included (provincial dealerships).
— Photo and Specifications may vary from actual unit.
— Additional ₱10,000 for Silky Pearl White color.
Isuzu mu-X Highlights
ISUZU mu-X 3.0L FEATURES
4-cylinder in-line Blue Power diesel engine with turbo intercooler
Bi-LED Headlamps
Horizontal Rear Combi Lamp with LED Positioning Lamp
New Redesigned Front Grille
255 / 60 R18 Two-tone Alloy Wheels New Redesigned Front Grille
(Available in LS-A Variant Only)
6-speed automatic transmission with sequential shift
Soft-pad interior with piano black accent and blue ambient light
Multiple USB charging ports with 12v accessory socket
Hill Start Assist (HSA) and Hill Descent Control (HDC)
8-inch Audio-Video Entertainment with Apple CarPlay, Android Auto, Navigation system, Wi-Fi display & USB Link.
10-inch roof mounted DVD Monitor
Automatic Climate Control
Passive Entry and Engine Push Start/Stop System
Cruise Control
Anti-Lock Braking System (ABS) / Electronic Brake Force Distribution (EBD) with Brake Assist (BA)
Electronic Stability Control (ESC) / Traction Control System (TCS)
5-link Coil Spring Suspension
255 / 60 R18 Wheels
SPECIFICATIONS
ENGINE
DRIVE TRAIN
| RZ4E 4X2 LS MT | RZ4E 4X2 LS AT | RZ4E 4X2 LS‑A MT | RZ4E 4X2 LS‑A AT | 3.0L 4X2 LS‑A AT | 3.0L 4X4 LS‑A AT | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Transmission | Model | MVL-6Y | AWR6B45-II | MVL-6Y | AWR6B45-II | ||||||||
| Type | 6 Speed Manual Transmission with Gear Shift Indicator | 6 Speed Automatic Transmission with Sequential Shift | 6 Speed Manual Transmission with Gear Shift Indicator | 6 Speed Automatic Transmission with Squential Shift | |||||||||
CHASSIS
| RZ4E 4X2 LS MT | RZ4E 4X2 LS AT | RZ4E 4X2 LS‑A MT | RZ4E 4X2 LS‑A AT | 3.0L 4X2 LS‑A AT | 3.0L 4X4 LS‑A AT | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Steering Type | Rack and Pinion with Power Assist | Rack and Pinion with Power Assist & Tilt Adjust | |||||||||||
| Brakes | Front | Ventilated Discs | |||||||||||
| Rear | Drum Brake | Ventilated Discs | |||||||||||
| Suspension | Front | Independent Double Wishbone with Coil Spring and Stabilizer | |||||||||||
| Rear | Five-link Coil Spring and Stabilizer Bar | ||||||||||||
| Tires and Wheel | 245/70 R 16 Aluminum Alloy | 255/60 R 18 Aluminum Alloy | |||||||||||
DIMENSION
| RZ4E 4X2 LS MT | RZ4E 4X2 LS AT | RZ4E 4X2 LS‑A MT | RZ4E 4X2 LS‑A AT | 3.0L 4X2 LS‑A AT | 3.0L 4X4 LS‑A AT | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Overall L X W X H | mm | 4,825 X 1,860 X 1,825 | 4,825 X 1,860 X 1,840 | ||||||||||
| Wheelbase | mm | 2,845 | |||||||||||
| Tread | Front / Rear | 1,570 / 1,570 | |||||||||||
| Ground Clearance | mm | 220 | 230 | ||||||||||
| Gross Vehicle Weight | kg | 2,650 | 2,750 | ||||||||||
EXTERIOR
| RZ4E 4X2 LS MT | RZ4E 4X2 LS AT | RZ4E 4X2 LS‑A MT | RZ4E 4X2 LS‑A AT | 3.0L 4X2 LS‑A AT | 3.0L 4X4 LS‑A AT | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Headlamps | Bi-LED Projector Headlamp with Integrated Day Time Running Lamps and Auto-headlamp Levelling | ||||||||||||
| Foglamps | - | Equipped | Equipped with chrome garnish | ||||||||||
| Antenna | Center Roof Type | ||||||||||||
| Radiator Grille | Material Gray | Chrome | |||||||||||
| Front Bumper | Upper: Color-keyed / Lower: Material Black | Upper: Color-keyed / Lower: Metallic Gray | |||||||||||
| Side View Mirrors | Material Black, Manual | Chrome-Finished Power Folding and Control with LED Integrated Turn Signal | |||||||||||
| Door Handles | Material Black | Chrome | |||||||||||
| Roof Rails | - | Equipped (Maximum load 60kgs) | |||||||||||
| Rear Spoilers | - | Equipped | |||||||||||
| Rear Bumper | Upper: Color-keyed / Lower: Material Black with Integrated Back-up Lamps | Upper: Color-keyed / Lower: Metallic Gray with Integrated Back-up Lamps | |||||||||||
| Rear Combination Lamp | Horizontal Type with LED Position Lamps | ||||||||||||
SAFETY
| RZ4E 4X2 LS MT | RZ4E 4X2 LS AT | RZ4E 4X2 LS‑A MT | RZ4E 4X2 LS‑A AT | 3.0L 4X2 LS‑A AT | 3.0L 4X4 LS‑A AT | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Dual S.R.S. Airbags | Equipped | ||||||||||||
| Seatbelts | 1st Row | Emergency Locking Retractor (ELR), Shoulder Adjust with Pre-tensioner and Load Limiter X 2 | |||||||||||
| 2nd Row | Emergency Locking Retractor (ELR) X 3 | ||||||||||||
| 3rd Row | Emergency Locking Retractor (ELR) X 2 | ||||||||||||
| Child Seat Tethers for Second Row | Equipped | ||||||||||||
| Side Door Impact Beams | Equipped | ||||||||||||
| Anti-lock Braking System (ABS) | - | Equipped | |||||||||||
| Electronic Brake Force Distribution (EBD) | - | Equipped | |||||||||||
| Brake Assist (BA) | - | Equipped | |||||||||||
| Brake Override System (BOS) | Equipped | ||||||||||||
| Electronic Stability Control (ESC) | Equipped | Equipped | |||||||||||
| Traction Control System (TCS) | - | Equipped | |||||||||||
| Hill Start Assist (HSA) | - | Equipped | |||||||||||
| Hill Decent Control (HDC) | - | Equipped | |||||||||||
| Under-Front Skid Plate | Resin | Steel with Transfer Case Protector | |||||||||||
| Anti-theft Alarm System | - | Equipped | |||||||||||
| Engine Immobilizer* | - | Equipped | |||||||||||
| Child Proof Rear Door Locks | Equipped | ||||||||||||
| High Mount Stop Lamp | Equipped - LED Type | ||||||||||||
| Reverse Camera | - | Equipped | |||||||||||
| Reverse Sensing System | - | Equipped - Metallic Gray Two-Eye Sensor | |||||||||||
| Rear View Mirror | Equipped day and Night Type | ||||||||||||
| Rear Defogger | Equipped | ||||||||||||
| Wipers | Front | Equipped - Intermittent Type | Equipped - Variable Intermittent Type | ||||||||||
| Rear | - | Equipped | |||||||||||
CONVENIENCE
| RZ4E 4X2 LS MT | RZ4E 4X2 LS AT | RZ4E 4X2 LS‑A MT | RZ4E 4X2 LS‑A AT | 3.0L 4X2 LS‑A AT | 3.0L 4X4 LS‑A AT | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Power Windows | Equipped with Auto Down for Driver | Equipped with Driver Auto Up/Down, Jam Protection and Timer Function | |||||||||||
| Power Door Locks | Equipped with Speed Sensing Auto Door Locks | ||||||||||||
| Entry System / Starting System | - | Passive Entry and Push Start/Stop System | |||||||||||
| Driver Seat Adjustment | Manual Standard | Manual with Height Adjust Control | Six-way Power Adjust | ||||||||||
| 12V Accessory Socket | Equipped X 1 | Equipped X 3 | |||||||||||
| USB Charging Port | Equipped X 1 | Equipped X 3 | |||||||||||
| Storage Compartment / Cup Holders | Nineteen Compartments / Twelve Cup Holders | ||||||||||||
| Glove Box | Equipped with Key Lock | Equipped with Key Lock and Illumination | |||||||||||
| Side Step Board | Equipped - Black Color | ||||||||||||
| Tow Hooks | Three (Front X 2 / Rear X 1) | ||||||||||||
